Tungsten Carbide Die carbide Stamping Die for Making Screws, Bolts and Nuts
Brief Introduction of Tungsten Carbide cold forging dies
Recommened grade:YL90.1, YL90.2, YL90.3, YL90.4, YL90.5
density: 13.0-14.5 g/cm3
HRA: HRA 81-85
T.R.S: 2350-2800 MPA
porosity: A02B00C00
FAQ
Q: Are you trading company or manufacturer ?
A: We are specialized manufactuer with 18 years' experience since 1998.
Q: How long is your delivery time?
A: Generally it is 10-15 days if the goods are not in stock, according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Quality grade of tungsten carbide cold forging dies
Main grade grade YL90(YG20C),YL90.4(YG24C),YL90.5(YG25C)
| Grade | Grain size (um) | Binder | density (g/cm³) | Hardness
(HRA) | T.R.S (N/m㎡) |
| YL80.2(YG15) | medium | 15% | 14.00-14.20 | ≥86.5 | ≥2900 |
| YL80.3(YG20) | fine | 20% | 13.50-13.80 | ≥85.0 | ≥2540 |
| YL80 | fine | 16% | 13.80-14.05 | ≥89.5 | ≥3200 |
| YL90(YG20C) | coarse | 20% | 13.50-13.70 | ≥83.0 | ≥2500 |
| YL90.1 | coarse | 16% | 13.90-14.10 | ≥84.5 | ≥2340 |
| YL90.2 | coarse | 18% | 13.70-13.90 | ≥83.5 | ≥2400 |
| YL90.4(YG24C) | coarse | 24% | 13.20-13.40 | ≥82.0 | ≥2600 |
| YL90.5(YG25C) | coarse | 25% | 13.00-13.20 | ≥81.0 | ≥2760 |
Package and delivery
Currently we have cartons,plywood case and metal drums.
Application of tungsten carbide cold forging dies
Tungsten carbide dies can be divided into four categories according to use:
1.Tungsten carbide anvil
2.Tungsten carbide drawing dies (such molds accounted for the vast majority of tungsten carbide die.)
3.Cold heading, cold punching, forming and shaping dies
4.Non-magnetic die
5.Hot tungsten carbide die
Metal working:processed into press tool,blade,cutter,wear parts,blanks and polishing tungsten carbide blocks for machinery lathe to machine HSS material,Alu,steel,and stainless steel,etc.
Production process of tungsten carbide cold forging dies
How to get exactly quotation based on clients requirements:
Necessary information required for manufacturing tungsten carbide cold heading dies:
- Specification ( like OD*ID*Length size,shape,angle etc.)
- Tungsten carbide grade, or chemical composition
- Surface condition: sintered blank or fine grinding
- Tolerance on dimension ( if you have)
- If you are not quite clear about which tungsten carbide grade is suitable, please provide us the applications to suggest you a suitable one.
P.S: Customized size carbide blocks are available here,your inquiry will be more than welcome,work with us!
